- FC8X is compatible with the following digital signal processor architectures:
- Biamp Tesira®
- QSC Q-SYS®
- Symetrix SymNet®
- Simplified control of Volume, EQ and DSP functions via Ethernet
- Built-in browser interface to add control values from your DSP configuration / design software
- LED backlit push buttons
- Custom program Faders, Buttons, & LED’s to your DSP functions
- POE+ | Power Over Ethernet network connection eliminates wireless connectivity issues and battery charging (802.3at compliant)
- Faders can be programmed to function as high, mid, and low frequency EQ controls
- Definable -db and lighting scale parameters
- Each channel’s push buttons can be programmed to controls in your DSP such as auto mixer on/off, auto gain control bypass, and channel on/off control
- Channel LED’s can be programmed to indicate status of auto mixer highest gain, signal presence, or other meter indicators
- Twelve user defined backlit push button switches are available to control fader banks 1 – 4, high, mid,or low EQ, system selections, or can be used to trigger DSP presets
- User definable push button control system selection or presets
Includes: 1ea EasyMix FC8X
Resources
FC8X Cutsheet
FC8X User Guide – coming soon
Technical Resources
EasyMix Discovery Tool
FC8X Firmware v
FC8X QSC Q-Sys Script
Symetrix SymNet Super-modules
A&E Specification
Easy Mix FC8X – DSP Control SurfaceThe DSP Control Surface shall provide remote control capabilities to supported digital signal processors over Ethernet. DSP Control Sur-face shall be equipped with eight (8) each physical fader channels and eight (8) Full-color HD displays. Each channel shall provide one (1) each 60 mm touch-sensitive motorized fader and two (2) each programmable functions via backlit tactile push button switches. DSP Control Surface shall provide programmable control of up to sixteen (16) each gain controls and additional field programmable functions within the device. The DSP Control Surface shall support the programming of eight (8) each customizable tactile push buttons and shall be able to be field programmable to control fader bank selection, EQ, presets, or logic functions depending on the options available for each digital signal processor. All tactile backlit push buttons shall be momentary, non-latching and shall provide integral LED status indi-cation. All program memory shall be non-volatile with no batteries required. Device setup shall be accessible using a built-in web server hosted within device and accessible with a web browser. DSP Control Surface shall have the following rear mounted connector: Ethernet RJ45. DSP Control Surface shall be constructed of and all electronics shall be enclosed in a matte gray, powder coated machine alumi-num chassis. DSP Control Surface shall be rack mountable in 4RU. DSP Control Surface faceplate shall in addition to make and model include a laminated positioning designation overlay at each fader. DSP Control Surface shall be Mystery Electronics EasyMix FC Series, model number FC8X. Note: If rack-mounting, additionally specify Mystery Electronics EasyMix FC Series rack-mounting hardware, part numbers: 1ea FCRMHW and 1ea FCRMFL.
