- UL and cUL Listed
- Flexible, easy to install, high capacity floor box pocket assembly
- Flat cover edges for flush mount applications (wood, tile, etc.)*
- Ceramic coated finish provides scratch resistance for long-term durability
- 12 gauge cover supports loads in excess of the 300lb UL standard
- Over-sized cable door exit limits “high-heel” trip hazard while allowing for cable(s) up to 1.25″ in diameter
- Integral basket hides construction rough-in box from view, providing a finished installation
- Compatible with all ModuLine Connector Insert Panels and/or Options
- Available provisions for AC Duplex power receptacle, Decora®, AAP®, MAAP® devices, or up to four (4) Neutrik® D type connectors, and more
- Concrete rated rough-in box available for installation above grade when conduit termination is required or otherwise preferred
Ideal for:
-
- Classrooms
- Houses of worship
- Conference rooms
- Courtrooms
- Performance venues
- Anywhere connections are needed in the floor. Design and finish also suitable for in-wall box applications.
Includes: 1ea cover, 1ea gasket, 1ea basket, and installation hardware. Compatible rough-in box, duplex power option, active low-voltage device panel(s), low-voltage connector insert panel(s), labeling, connectors, and accessories also available.
*Caution: To avoid trip hazards, the flat FMCA1200 floor box cover must be correctly installed flush with the finished floor surface. The flat trim option is not suitable for use on top of carpet, concrete, sheet vinyl, vinyl, tile, or similar hard surface materials. The flat trim option should only be used when inset into wood, grouted masonry tile, terrazzo, or poured composition flooring. To ensure a proper result, flush installation requires significant coordination between several trades and special care during installation. If not mounting flush with floor, please use self-trimming models FMCA1000 or FMCA1400 with integral beveled edges.
