  • Create a custom wall plate appearance from cost effective in-stock panels
  • 1-gang audio video connector panel
  • Satin Black or Brushed Stainless finish
  • Heavy-duty 14 gauge construction
  • Variations for mounting up to two (2) FlexiConn Connectors also available
    IN STOCK – Request Support or Dealer Referral

FP-1G Series Panel FP-1G-0-B offers a custom 1-gang wall panel appearance from cost effective in-stock plates.

        • Mounts on standard trade size 1-gang rough-in box
        • Vertically positioned connector mounting for professional appearance
        • Blank panel for onsite customization
        • Laser-cut precision eliminates warped panels
        • Satin Black Ceramic finish or Brushed Stainless Steel provides scratch resistance for long term durability
      • Radiused corners achieve modern custom aesthetic
      • Heavy-duty 14 gauge steel construction
      • Combine with available full panel labeling for a distinctive signature to any project
        • Your logo graphic with our unlimited labeling colors creates a complete panel solution

      FP-1G-0-B | 1 gang, Black, Blank
      FP-1G-0-S | 1 gang, Stainless, Blank
      FP-1G-1-B | 1 gang, Black, 1ea Neutrik D®
      FP-1G-1-S | 1 gang, Stainless, 1ea Neutrik D®
      FP-1G-2-B | 1 gang, Black, 2ea Neutrik D®
      FP-1G-2-S | 1 gang, Stainless, 2ea Neutrik D®

      Includes: 1ea FP-1G-*-* Panel and mounting screws.  Compatible labeling, low-voltage connectors, and accessories also available.

Weight 1 lbs
Gang Size

1-Gang
Overall Dimension (nominal)

4.5L x 2.75W in
Connector Capacity

0 (Blank), 1ea FlexiConn (or equivalent), 2ea FlexiConn (or equivalent)
Finish

Satin Black, Brushed Stainless Steel
Assembly

1ea FPG Panel and mounting screws
Warranty

2 Years

Resources

Cut Sheet

Dimensions

Related

Connectors

FPG Series AV Connector Wall Panels

Connector Panel Labeling

A&E Specification

FP-1G-*-B – Gang Wall Panel, Satin Black (Ceramic Coated) Wall panel shall be of 14 gauge steel, shall have radiused corners to .375, shall accommodate _ connector(s) (0ea, 1ea, or 2ea), and shall be provided with #6 stainless steel screws.  Panel shall have a ceramic plastic satin black finish so as not to create specular light reflections.  Panel shall mount on standard trade size gang box.  Panel shall be Mystery Electronics FP-1G-*-B.  (determine connector quantity to specify model number)

FP-1G-*-S – Gang Wall Panel, Brushed Stainless Wall panel shall be of 14 gauge steel, shall have radiused corners to .375, shall accommodate _ connector(s) (0ea, 1ea, or 2ea), and shall be provided with #6 stainless steel screws.  Panel shall consist of stainless stell with a brushed finish.  Panel shall mount on standard trade size gang box.  Panel shall be Mystery Electronics FP-1G-*-S.  (determine connector quantity to specify model number)
